LED mesh display screen P50 outdoor

Specification model: CY-20-P50-1C
Lamp size: Φ20 (mm)
Shell material: PC mask
Light source: SMD5050RGBx1
Control mode: TTL breakpoint transmission
Point spacing: 50X50mm
Brightness: 1000CD/㎡
Input voltage: DC12V
Maximum power: 120W/㎡
Working temperature: -25℃~ 60℃
Protection level: IP67
Working life: ≥50000H
Installation method: Wire rope suspension installation

product details

1. Use an enlarged wire diameter point light source to support
longer-distance power supply and signal transmission.
2. Flexible installation methods: The product is small in size and
light in weight. With the soft steel wire rope, flexible and diverse
installation methods can be achieved.
3. It has the function of resuming transmission of dead pixels.
Even if one of the pixels is damaged, it will not affect the signal
reception of subsequent pixels, minimizing the product failure
rate.
4. Multiple spacing options to flexibly control project costs
